What is the difference between the H66 and the H68?

The H66 is the indoor model: plug-and-play with an emergency power-off alarm, up to 5 km range and an IP67 enclosure. The H68 is the outdoor model with up to 10 km range, IP68, and a design for long-term outdoor service.

Which frequency bands does it support?

CN470, EU868, IN865, RU864, US915 and AU915, matching regional LoRa band plans.

What happens if the power fails?

The gateway raises an emergency power-off alarm over its 4G backhaul, so the operations team knows immediately that the sensor network is offline.

How many sensors can one gateway serve?

A full-duplex industrial gateway can serve large sensor fleets; actual capacity depends on reporting interval, payload, and network conditions — share your device count and Hitelecom will size the network.

H66 Series · Indoor Gateway

Industrial | Long-Range | Full-Duplex

The Hitelecom H66 indoor gateway is an industrial full-duplex LoRa gateway for in-building sensor networks: up to 5 km range, -140 dBm sensitivity, regional bands from CN470 to US915, plug-and-play setup with emergency power-off alarm, 4G backhaul and MQTT uplink.

Request a Quote Download Datasheet

Home / Products / Indoor

Back to Products

Key Features

Industrial | Long-Range | Full-Duplex

Communication Range up to 5 km (Open Area)
IP67 Waterproof and Dustproof Rating
Industrial 8-Channel Full-Duplex Gateway
Supports local deployment for data control and reliability
Integrated Power Amplification and Low-Noise Amplifier Circuit
Wireless options: 4G LTE, NB-IoT, and LoRa.
Large-Capacity Networking, Remote Control and Data Acquisition
Can send a power-loss alert when backup power and backhaul remain available

Technical Specifications

H66 Series Industrial Multi-Channel Wireless Gateway supports multiple protocols, offers 8-channel full-duplex, edge computing, withstands harsh conditions, and enables real-time data processing and remote management.

Specifications

H66 Series · Indoor Gateway — Technical Specifications
Product Models	H66
Frequency Bands	CN470/EU868/IN865/RU864/US915/AU915
Distance	Up to 5 km (open area)
Transmit Power	20dBm~27dBm
Sensitivity	-140dBm@0.292Kbps
Antenna	External Fiberglass Antenna
4G band	LTE-TDD: B34/B38/B39/B40/B41; LTE-FDD: B1/B3/B5/B8
Protocol	MQTT
Operating Temperature	-20°C to +70°C
Storage Temperature	-20°C to +80°C
Installation	Ear mount, pole clamp, or slot mounting (varies by configuration)

Application Scenarios

Building Management

Energy management

Logistics

Industrial

Smart city

Water management

Intelligent transportation

Applications

This product supports the following monitoring applications:

Building management

Collects HVAC, metering and environment sensors across floors from a comms room.
Energy management

Aggregates sub-metering sensor traffic for factory and building energy audits.
Logistics and warehousing

In-warehouse sensor collection for temperature, door and asset beacons.
Industrial facilities

Shop-floor sensor networks without running data cables.
Water management

Pump-room and tank-level sensor aggregation inside utility buildings.
Transportation facilities

Sensor collection inside stations, tunnels and depots.

Frequently Asked Questions

What is the difference between the H66 and the H68?: The H66 is the indoor model: plug-and-play with an emergency power-off alarm, up to 5 km range and an IP67 enclosure. The H68 is the outdoor model with up to 10 km range, IP68, and a design for long-term outdoor service.
Which frequency bands does it support?: CN470, EU868, IN865, RU864, US915 and AU915, matching regional LoRa band plans.
What happens if the power fails?: The gateway raises an emergency power-off alarm over its 4G backhaul, so the operations team knows immediately that the sensor network is offline.
How many sensors can one gateway serve?: A full-duplex industrial gateway can serve large sensor fleets; actual capacity depends on reporting interval, payload, and network conditions — share your device count and Hitelecom will size the network.
